Dual Axis Solar Tracking Bracket System
Dual Axis Solar Tracking Bracket System
Dual Axis Solar Tracking Bracket System

Dual Axis Solar Tracking Bracket System

Basic Parameters
Product Type: Single-Post Dual-Axis Tracker
Drive Mechanism: Slewing Reducer / Linear Actuator
Tracking Range: E-W: ±120°, N-S: 0-70°
Foundation Type: Concrete Foundation
Wind Resistance Design: 47 m/s
High Wind Protection: Activated at 18 m/s
Number of Modules: ≤30 modules
Minimum Ground Clearance: 0.5 m (or project-specific)

Automation System Parameters
Tracking Mode: Astronomical Algorithm / Active Tracking / Anti-Shadowing AI
Tracking Accuracy: ≤1°
Control Method: MCU Closed-Loop Feedback Control
Control Precision: ≤0.3°
Power Supply Mode: String Power Supply / AC Power from Substation
Supply Voltage: DC 1500 V / AC 220 V
Communication Method: Zigbee Wireless / Modbus
Monitoring Device: SCADA (Optional)
Ingress Protection Rating: ≥IP65
Weather Protection: High Wind / Snowfall / Hail

CONTACT US
PREV: Oblique Single Axis PV Tracking System
NEXT: No next product

Description

Detailed images

Contact us

The dual-axis tracking bracket achieves real-time and precise alignment of the sun's movement trajectory throughout the day through the coordinated rotation of two degrees of freedom, namely the azimuth Angle and the elevation Angle, thereby capturing direct radiation to the greatest extent. In application scenarios where the maximum power generation per unit area is pursued or high-precision energy output is required, the dual-axis bracket is an irreplaceable top solution.

Detailed description of advantages

Ultimate power generation gain: Through full-angle tracking, its power generation can be increased by 25% to 40% or even more than that of the optimally inclined fixed bracket system, especially in areas with a high proportion of direct radiation, its performance is unparalleled.

All-day high-efficiency power generation: From sunrise to sunset, the surface of the components always maintains an Angle close to the vertical of the sunlight, achieving the longest high-efficiency power generation time each day, with a very stable output curve.

Improving low-light performance: In the early morning, evening and on cloudy days, due to its precise alignment with the sun, the power generation starts earlier and stops later, significantly enhancing the power generation efficiency during low-light periods.

It is suitable for complex terrains and high-value occasions: Its independent tracking feature enables it to better adapt to mountainous areas with complex slopes, and it is also an ideal choice for solar experimental power stations, special power supply and display projects.
